IER-F Series IE020R-F
P2 LED Signage that offers an ideal combination of superior picture quality and intuitive usability.
- Cost-saving solution through easier installation and affordable price
- Support for various installation scenarios through flexible design
- LED HDR technology for clear, accurate picture presentation
Discover our LED Configurator.Samsung Configurator is a simulation tool that enables you to virtually install Samsung’s LED display and precisely determine your needs and desired result in advance.
Captivate potential customers
Samsung’s IER series LED displays deliver stunning picture quality at a cost-efficient price point. This displays can be custom-fit for the specific space requirements, giving customers a more immersive experience.
Easier, cost-saving installation
The IER series supports two cabinet types. One version features a larger, lighter screen compared to conventional cabinets, simplifying installation. The other is a quarter of the size and provides more flexibility in design.
The IER series’ advanced design provides flexibility for any indoor retail or other business environment. With support of portrait and landscape orientation — and even curved* and l-shaped installations - content can be displayed to meet the preferred layout for any store location.
Clearly refined visuals
LED HDR leverages advanced refinement technologies for true-to-life picture presentation. Dynamic Peaking and Inverse Tone Mapping enhance content to optimum peak brightness levels with improved contrast and without shine, and in-depth Color Mapping ensures an accurate expression of colors.
Accurate color in low brightness arena
Conventional LED displays struggle to present red, green and blue color hues accurately in low grayscale settings. The IER series overcomes these challenges through a unique algorithm that maintains R/G/B gradation and delivers precise, detail-rich hues in low-brightness indoor environments.
Rigorous factory calibration and real-time DSLR camera sub-pixel calibration fine-tune all sub-pixels for uniform brightness and color chromaticity. When coupled with the Samsung LED Signage Manager’s advanced picture settings, this enhanced treatment produces an excellent presentation.
Streamlined UHD content delivery
Samsung’s compatible S-Box condenses the delivery of compelling content to a single, centralized device. The S-Box transmits UHD content across multiple IER series displays without requiring external boxes or splitters, helping businesses enjoy faster and more cost-efficient operations.
Manage content and devices anywhere
Compatibility with the MagicINFO platform enables IER series users to create, schedule and deploy content across an entire signage network. Users likewise can monitor and adjust display settings and troubleshoot potential performance issues from any location via remote access.
- Pixel Pitch2.0 mm
- Pixel Configuration1 red, 1 green, 1 blue
- Configuration (LxH, per cabinet)120x270 pixels
- Diode TypeSurface Mount Device (SMD)
- Dimensions (㎜, LxHxD, per cabinet) 240x540x81 mm
- Diagonal (inch, DiagonalxD, per cabinet)23.3 inch x 3.18 inch
- No. of Modules (WxH, per cabinet)1 x 3
- Weight (per cabinet/per ㎡) 3.2Kg / 24.7Kg
